The 123 series gate valve in forged steel A182 F11, Class800, TRIM 5, F/F NPT, with welded bonnet, standard bore, non-rotating rising stem for oil, steam, high pressure industries.
| Specification | Value |
|---|---|
| DN inches NPS | 1/2'' |
| Option certificate 3.1 | Yes |
| Bonnet material | Carbon steel ASTM A182 F11 |
| Construction standard | ISO 15761 - API 602 V8 |
| CE risk category | III Module H |
| TRIM | TRIM 5 |
| Brand | OMB |
| Tightness test standard | API 598 |
| Bonnet | Welded |
| Steam | Yes |
| Opening device | Handwheel |
| Application | Industry |
| ATEX atmosphere | Group II Cat. 2G/2D |
| Shaft/stem matérial | Stainless steel AISI 410 |
| ATEX compatible | Yes |
| DN | DN15 - 1/2'' |
| Face to Face (mm) | 80.0 |
| Sealing | Metal / Metal |
| Fluid | Hydrocarbons. gas |
| Kv (m³/h) | 4.8 |
| Body material | Carbon steel ASTM A182 F11 |
| Gate material | Stainless steel ASTM A182 F6a stellited |
| Bore | Standard |
| Packing gland | Yes |
| PS (bar) | 138 |
| Connections | NPT FF |
| Seats | Stainless steel ASTM A276 Tp 410 stellite |
| TS max (°C) | 540 |
| TS min (°C) | -29 |
| ATEX zone | 1 & 21. 2 & 22 |
| Warranty period | 2 years |
| Type of stem | Rising |
| CE | Yes |
| Main product colour | Black |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| NPT FF Carbon steel ASTM A182 F11 Standard 1/2'' | 123004 | S1007509 |
€142.59
(excl. btw)
|
add to cart |
| NPT FF Carbon steel ASTM A182 F11 Standard 3/4'' | 123005 | S1007510 |
€142.40
(excl. btw)
|
add to cart |
| NPT FF Carbon steel ASTM A182 F11 Standard 1'' | 123006 | S1007511 |
€209.41
(excl. btw)
|
add to cart |
| NPT FF Carbon steel ASTM A182 F11 Standard 1''1/2 | 123008 | S1007512 |
€456.24
(excl. btw)
|
add to cart |
| NPT FF Carbon steel ASTM A182 F11 Standard 2'' | 123009 | S1007513 |
€549.16
(excl. btw)
|
add to cart |
